MFD-635-2S Fiber Pigtailed Laser Diode

  • Item No.: MFD-635-2S
  • Wavelength: 635 +/- 5 nM
  • Output power: 2 mW
  • Fiber core diameter: 4 um
  • Fiber connector: FC
  • N.A.: 0.13
  • Package: Coaxial
  • Threshold current (Ith): < 35 mA
  • Operating current (Iop): < 40 mA
  • Monitor current (Im): 100 - 400 uA
  • Pigtailed Laser Diode

    Disclaimer: The specifications are subject to change without notice.
